1.The remote controller control start, stop, forward/backward, steering, vibrating, and monitor the temperature of oil, water, etc.
2. It is very safe for operator, especially used in the limited and dangerous area.
3. Famous Honda or Yanmar engine.
4. Hydraulic drive, vibration & steering.
As one of the professional remote control roller manufacturers in China, ASOK has always enjoyed a good reputation
Type | RWYL202C |
Run | |
Speed | 1.2km/h(low) 2.4km/h(high) |
Turning radius | 1700mm |
Climbing capacity in theory | 50% |
Compaction | |
Static load forward/back | 98/90N/cm |
Nominal amplitude | 1.7mm |
Vibration frequency | 42Hz |
Exciting force | 70kN/35kN(Hydraulic control) |
Engine | |
Model | Yanmar 3TNV80F |
Type | Diesel engine, water cooled, 4stroke, three cylinder |
Power | 17.8 KW/3000rpm |
Fuel tank volume | 30L |
Lubricant L | 2.2L |
Fuel consumption | 272g/kWh |
Dimension | |
Width of steel wheel | 600mm/850 mm |
Diameter of steel wheel | 520mm |
Tread | 1000mm |
Total length | 1900mm |
Total width | 850mm |
Total height | 1300mm |
Packing size | 2184 x 1024 x 1513 mm |
Weight | |
MAX. working weight | 1635kg |
