1. Custom made water-cooled diesel engine,with good heat dissipation and great power comparing to gasoline engine,especially fits for running in burning hot areas.
2. Drum and body steel material is C45,better tensile strength than Q235,long service life.
3. Steel cutting by lazer,no deformation from twisting and bending,high demension accuracy comparing to flame cutting
4. 65 Liters, corrosion-free water tanks mounted at the rear of roller reduces reduces sound and keeps dust to a minimum.
5. Vibration is controlled by easy to reach on and off switch in speed controlled hand lever.
6. Two scraper bars on each drum ensure a clean drum when working on asphalt.
7. Minimum overhang offering suitable side and curb clearance.
8. Ergonomically design handle with dead man control offering protection to operator in reversing applications.
| Model | RL500D | RL600D | RL700D | RL900D |
| Engine | Diesel engine 178F 6.0HP | Diesel engine 186FE 9.0HP | ||
| Weight (KGS) | 630 | 720 | 740 | 810 |
| Vibratory Frequency (times/min) | 3600 | 3600 | 3600 | 3600 |
| Centrifugal Force (KN) | 15 | 20 | 24 | 30 |
| Max. Travelling Speed (KM/H) | 2.5 | 2.5 | 2.5 | 2.5 |
| Gradeability (%) | 20 | 20 | 20 | 20 |
| water tank capacity (L) | 32 | 35 | 35 | 35 |
| fuel tank capacity (L) | 25 | 25 | 25 | 25 |
| Vibratory Wheel Dia (mm) | 377 | 377 | 426 | 426 |
| Vibratory Wheel Width (mm) | 600 | 650 | 650 | 700 |
| packing size(cm) | 131*74*112cm (handle 162*31*38) | |||
