ACE 3600KGS Ride on Vibration roller is suitable for compaction of asphalt, compaction of non-cohesive and cohesive soil and compaction of stabilized soils. It is used primarily for small-scale compaction work such as pavements, cycle paths, small roads and small parking areas-places that need compaction but are difficult to reach with a larger roller
1.Famous brand KOHLER KDW1404 Diesel engine,excellent performance, easy to start-up;
2.Famous Italy variable pump, fixed displacement motor, steppless speed, easy to change direction;
3.Ergonomic layout and design of the operating controls:the easy drive steering wheel,multifunctional control lever,and comfortable armrests .
4.Flip-open engine hood provides easy accessibility to engine and components for daily maintenance and service .
5.Large 200L water tank is equipped with pressurized water system offers consistent water flow
Ride-on Double drum Vibratory roller RZ240V
1.Powerful KOHLER KDW1404 Diesel Engine:The roller is equipped with a renowned KOHLER KDW1404 Diesel engine, known for its excellent performance and easy start-up. This engine ensures reliable power to drive the compaction process effectively.
2.Italian Variable Pump and Fixed Displacement Motor:The roller features a high-quality Italian variable pump and fixed displacement motor, providing stepless speed control and easy direction changes. This allows for precise and efficient operation during compaction.
3.Ergonomic Operating Controls:The design of the operating controls is ergonomic and user-friendly. The easy drive steering wheel, multifunctional control lever, and comfortable armrests contribute to an operator-friendly experience, enhancing productivity and reducing fatigue.
4.Convenient Maintenance:The roller is designed with a flip-open engine hood, providing easy accessibility to the engine and components for daily maintenance and service. This feature ensures that routine maintenance tasks can be performed efficiently, minimizing downtime.
5.Pressurized Water System with Large 200L Tank:The RZ240V comes equipped with a large 200L water tank featuring a pressurized water system. This system ensures a consistent water flow during the compaction process, contributing to improved compaction results and dust suppression.
|
Model |
RZ240V |
RZ235V |
|
Weight |
3600kg |
3300kg |
|
Max Working Weight |
3900kg |
3500kgs |
|
Triction |
||
|
Rated Speed |
9km/h |
9km/h |
|
Vertical Pendulum Angle |
±7° |
±7° |
|
Gradeability |
40% |
40% |
|
Compacting |
||
|
Centrifugal Force |
32KN |
32KN |
|
Static Line Force |
154/161kg/cm |
154/161kg/cm |
|
Vibration Frequency |
60Hz |
60Hz |
|
Water Tank Capacity |
200L |
200L |
|
Engine |
||
|
Manufacturer |
KOHLER KDW1404 |
KOHLER KDW1404 |
|
Type |
Water-Cool Engine |
Water-Cool Engine |
|
Rated Power |
21.7kW |
21.7kW |
|
Oil Capacity |
40L |
40L |
|
Hydraulic System |
||
|
Hydraulic Pump |
Poclain |
Poclain |
|
Hydraulic Motor |
Poclain |
Poclain |
|
Emergency Braking/Stop |
Emergency Button |
Emergency Button |
|
Measurement |
||
|
Whole Machine Size |
2745x1430x2650mm |
2745x1430x2650mm |
|
Packing Size |
2745x1430x2650mm |
2745x1430x2650mm |
