2000W-18000rpm High Frequency concrete vibrator. A very light and easy to handle concrete vibrator that comes with a shoulder strap for easy transport.
ZID-UL-200J Electric vibrator with shaft compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.ACE ASOK Machinery summarizes the defects of past products, and continuously improves them. The specifications of ZID-UL-200J Electric vibrator with shaft can be customized according to your needs.
As a professional concrete vibrator manufacturer, we have always enjoyed a good reputation all over the world.
The ZID-UL-200J, a Japanese-style high-frequency electric concrete vibrator, boasts a powerful 2000W power output, a stable 220V voltage, a rated frequency of 50Hz, and a no-load speed of 4000 r/min, easily meeting various concrete vibration requirements. Weighing only 6.35kg, it features a convenient shoulder strap design, significantly reducing operator fatigue and enabling flexible single-person operation and transportation.
It is one of the most widely used products, known for its low noise, energy efficiency, reliable functioning, high safety, and good vibrating performance.
Electirc Concrete vibrator
Electric concrete vibrator ,Japanese type | |
Model | ZID-UL-200J |
Rated input power | 2000W |
Rated voltage | 220V |
Rated Frequency | 50HZ |
No-load speed | 4000 r/min |
Weight | 6.35kgs |
Its matching ZX series high-frequency vibration shaft (ZX-35/38/45) offers multiple specifications: head diameter of 35-45mm is suitable for different construction scenarios, 200Hz high-frequency vibration and 0.91-1.2mm precise amplitude ensure the density of concrete, and flexible hose and 10mm diameter flexible shaft support customization of 2-6 meters in length, making it easy to penetrate complex structures.
Match concrete vibrator shaft
Item | High-frequency vibrator shaft | |||
Model | ￠(mm) | ZX-35 | ZX-38 | ZX-45 |
Diameter of head | ￠(mm) | 35 | 38 | 45 |
Length of head | L (mm) | 330 | 370 | 390 |
Vibrating Frequency | (HZ) | 200 | 200 | 200 |
Vibrating Ampitude | (mm) | 0.91 | 1.2 | 1.2 |
Diameter of flexiable hose | D(mm) | 30 | 30 | 30 |
Diameter of flexiable shaft | D(mm) | 10 | 10 | 10 |
Length | mtr | 2/3/4/5/6 mtr | 2/3/4/5/6 mtr | 2/3/4/5/6 mtr |
packing size | cm | 75*75*5.5cm | ||
Product Details
Since our oversea distribution network was established in 2005, we have secured export destinations in regions including the Americas, Africa, Eastern Europe, Southeast Asia, the Middle-East, etc.
Company was founded in 1995 which have 26 years’ experience in the road construction machinery.
ACE tools are approved by industry standards such as CE and CCC. Starting in 2009, our production facilities have been audited on a yearly basis by professionals from the TÜV SÜD Group.
Now we have the products almost including all kinds of small road construction machines like the concrete mixer, concrete vibrator, plate compactor, tamping rammer and power trowel.
