After years of development, Ningbo Ace Machinery Co.,Ltd. has gained strong capabilities in production and R&D, which allows us to develop new products to keep close up with industry development. High-end technologies are adopted to manufacture the product.When the product is manufactured and used in the field(s) of Rebar Bending Machine, its stability and advantages can be fully played out. Looking to the future, GW40/3KW/380V Construction Machinery Rebar bender for Sale will continue to follow the route of independent innovation, and continue to introduce high-tech talents as intellectual support, and strive to achieve the goal of becoming a world-class enterprise.


Place of Origin:Zhejiang, ChinaBrand Name:KZW
Condition:NewModel Number:GW40
Material / Metal Processed:AluminumAutomation:Manual
After-sales Service Provided:No overseas service providedExtra Services:End Forming
Power:HydraulicCertification:ce
Machine Type:Roll Forming MachineRaw Material:Steel Bar
Power::3.0KWVoltage::380V
Bending Dia of steel bar::6~40mmWorking plate Dia::320mm
Speed of motor::1420r/minNet weight::232KGS
Packing size::790*790*880mm


Rebar bender GW40/3KW/380V





Product introduction:

Bar bending machine GW40 is ideal equipment for steel bar bending working.This model has reasonable design,simply structure.It enables to bend bars of diameters 6~40mm to various shapes,which is applicable in many kinds of construction projects such as bridge,tunnel etc.





Characteristic:

 Bar bending machine is made of thickened steel plate,hard steel bar,and  copper wire motor with full power .Closed gear box,low noises,special motor wheel which can adjust speed.We specially add eccentric sleeve and adjustable baffle to the accessories.The accessories are made by C45 steel ,which can be used for a long time.





Main Technical information:

ITEM

Steel bar bender machine

Model

GW40

GW50

Bending round steel diamete

6-40mm

6-50mm

ⅡGrade thread screw steel diamete

6-32mm

6-42mm

Working plate diameter spec

320mm

420mm

Main shaft speed

8-15r/min

8-15r/min

Motor spec

3KW/380V

4KW/380V

Motor speed

1440t/min

1440t/min

Dimension

750×700×710mm

1060×850×730mm

Net weight/Gross weight

232kgs/252kgs

380kgs/400kgs

packing size

790×790×880mm

1100×860×860mm



SPARE PARTS:







PRODUCE DEPARTMENT:











PICTRUE OF PACKING:
