1500W-2300W High Frequency concrete vibrator. A very light and easy to handle concrete vibrator that comes with a shoulder strap for easy transport.
The vibrator incorporates off-centered weights into the 18000rpm electric motor to generate high frequency vibration.
Via the flexible tube, the vibrator transmits the vibration to the poker via the flexible tube.
It is spun as much as 12,000 times per minute, which makes it easy to cause resonance with the poured concrete.
As one of the professional concrete vibrator manufacturers in China, ASOK has always enjoyed a good reputation
Type | Europe type | |
Model | ZID--150 | ZID-230 |
Rated input power | 1500W | 2300W |
Rated voltage | 220V | 220V |
Rated Frequency | 50HZ | 50HZ |
No-load speed | 18000 r/min | 18000 r/min |
Weight | 5.24kgs | 5.5kgs |
Packing size | 34*20.5*26cm | 34*20.5*26cm |
Item | High-frequency vibrator shaft | |||
Model | ￠(mm) | ZX-35 | ZX-38 | ZX-45 |
Diameter of head | ￠(mm) | 35 | 38 | 45 |
Length of head | L (mm) | 330 | 380 | 390 |
Vibrating Frequency | (HZ) | 200 | 200 | 200 |
Vibrating Ampitude | (mm) | 0.91 | 1.1 | 1.2 |
Diameter of flexiable hose | D(mm) | 30 | 30 | 30 |
Diameter of flexiable shaft | D(mm) | 10 | 10 | 10 |
packing size | cm | 75*75*5.5cm | ||
