Vertical Mast Lift
VR

Product configuration

Aluminum profiles:CITIC Bohai AluminumControl box:Heipu, Italy
Power unit:Jiangsu WeiboWear-resistant cable:Jianghao (Sino Hong Kong joint venture)
Explosion-proof valve:Lesch, ItalyTravel switch:Delixi
Sealing ring:Japan NOKInstitute of Sliders:Chongqing Research
Oil cylinder:Chuzhou Kangda




Technical Parameter


Platform load:150KGAC lifting motor:0.75KW
Maximum number of employees:1 personAC operating weight:330KG
Maximum platform height:4.7MCharging time:(6-8) h
Maximum working height:6.7MLifting times :

60-70 times

Vehicle length:1.24MBattery:100AH maintenance free
Vehicle width:0.74MLifting motor:1.5KW
Vehicle height:1.99MOperating Weight:355KG
Platform size:0.67M * 0.66M * 1.1MCharger:12V15A
Support range:1.7M * 1.7M



Product selling points




Walking and lifting (walking and lifting can be completed through the upper control handle operation to improve work efficiency)



Extension platform (capable of crossing obstacles and quickly paving to the working point.)



Turning radius (minimum turning radius and compact design facilitate working in narrow spaces)



Emergency descent (equipment can be manually lowered in case of power failure or emergency)




Explosion-proof oil cylinder (once the oil pipe breaks, the explosion-proof valve automatically opens, and the platform stops in the air, waiting for rescue)



Climbing ability (25% climbing ability, able to smoothly climb the slope)



Convenient maintenance (automatic display of fault codes for easy maintenance)



Sealing ring (NOK sealing ring, no oil leakage when the equipment is parked for a long time)


 Safety testing



Mechanical strength (more than ten times the test requirement)



Hydraulic load carrying capacity (more than eight times the test requirement)



Electrical Appliances (with European EC Declaration of Conformity)



Anti tipping test (150% full load, 4 times the maximum inclination angle, 200N horizontal force, load on the most unfavorable side, ensuring that the equipment does not tip over)




FAQ

1.Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis / Conformance; Insurance; Origin, and other export documents where required.
2.What is the product warranty?
We warranty our materials and workmanship. Our commitment is to your satisfaction with our products. In warranty or not, it is the culture of our company to address and resolve all customer issues to everyone’s satisfaction
3.What is the average lead time?
For samples, the lead time is about 7 days. For mass production, the lead time is 20-30 days after receiving the deposit payment. The lead times become effective when (1) we have received your deposit, and (2) we have your final approval for your products. If our lead times do not work with your deadline, please go over your requirements with your sale. In all cases we will try to accommodate your needs. In most cases we are able to do so.
