Model:JCPT03PA/JCPT04PAMaximum number of employees:1 person
Safe working load:240kg
Minimum ground clearance:0.05m
Maximum working height:5m/5.9mRising and falling speed:34/20SEC   34/25SEC
Maximum platform height:3m/3.9mLifting motor:12V/0.8KW
Overall length:1.32mBattery:12V/100AH
Overall width:0.76mCharger:12v/12A
Overall height:1.83m/1.92Maximum gradeability:25%
Working platform size (length * width * height):1.15 * 0.6m * 1.1mMaximum allowable working angle:1.5 °
Wheelbase1mOperating Weight:482kg

Product configuration:

dual brake front wheels. Platform self-locking door. Standard shipping forklift holes. Level indicator. Charging indicator. Emergency descent system. Maintain the support rod safely. Anti misoperation button. Oil pipe explosion-proof system

The following table shows the product materials:

Safety guardrail adopts:35mm * 35mm square tubetraction battery:Maintenance free battery
platform:anti-skid patterned plate of 3mmHydraulic oil:Great Wall brand N46 # anti wear
Explosion-proof valve:Lesch, ItalyPump station:Weibo
Welding of bottom frame:Q345 manganese steel plateSupporting rod material:QSTE500TM special steel rectangular tube
Sealing ring:Japan N0KSurface treatment:machine spray molding
Hydraulic cylinder:Jiangsu Hengli
